The range · Made in Bayswater, Melbourne · Delivery Australia wide

Timber Fretwork & Frieze Panels

Call 03 9720 1996 Choose fretwork sizes and prices Browse designs ↓ Match from a photo

Compare complete assembled panels separately from individual repair components. Each product below shows its own price and unit.

Every price and size, with photographs and Add to quote →

Timber fretwork finishes the bay between verandah posts or decorates an indoor opening. Choose external fretwork for the verandah, internal fretwork for hallways and archways, or frieze panels for a continuous decorative band. Compare designs, dimensions and prices below. For a replacement, send a photograph and measurements so we can help match the existing detail.

Exterior verandah design reference. The exact product code and project supply are not identified.

Choose the range for your opening:

Compare the range

Compare fretwork and frieze panel designs

Start with a complete external panel design below. Open the component and profile collections for matching repairs, internal fretwork and frieze patterns. Prices include GST; delivery is quoted separately.

Complete external panel designs

$607.67per lineal metre
Made to your opening.Details & quote
$221.02per lineal metre
300 mm overall height.Details & quote
$221.02per lineal metre
300 mm overall height.Details & quote
$853.80per lineal metre
Made to your opening.Details & quote
Compare FR4 panels and motif options
$176.80per lineal metre
300 mm overall height.Details & quote
$151.55per lineal metre
300 mm overall height.Details & quote
$458.00per lineal metre
Made to your opening.Details & quote
$439.62per lineal metre
Made to your opening.Details & quote
$203.24per lineal metre
300 mm overall height.Details & quote
$197.50per lineal metre
300 mm overall height.Details & quote
$607.67per lineal metre
Made to your opening.Details & quote

Choose external fretwork sizes and request a quote →

Repair components and motifs · 13 pictures

Fretwork component sizes and prices

Internal fretwork and frieze profiles · 70 pictures

Preview the internal HFR/DFR patterns at your opening size

Timber fretwork frieze panel - pierced fretwork valance spanning an interior opening

Scale profiles

Frieze panel sizes and prices

Choose the fretwork for your opening

External fretwork

For verandahs and outdoor openings. Straight FR2, FR3, FR4, FR5 and FR8 panels have a 300 mm overall drop.

External fretwork sizes and prices

Internal fretwork

For hallway arches and indoor openings. Check the material and dimensions listed for your selected code.

Internal fretwork designs and prices Preview 19 internal fretwork patterns

Frieze panels

For a decorative band across an opening. Compare the pattern and panel dimensions before choosing.

Frieze panel patterns and prices

For a repair, compare the fretwork component prices or send a photograph and measurements through our timber matching service.

Try your opening before you enquire

See internal fretwork at your own opening size

Heritage’s free internal fretwork visualiser redraws 19 HFR and DFR patterns using your opening width and height in millimetres. Compare the silhouette or line drawing, try finishes, then copy the pattern and measurements for your quote.

Try the internal fretwork visualiser

Internal HFR/DFR patterns only. External FR panels, A/B/C/G friezes and assembled FRI1/FRI3/FRI5 designs are outside this tool. It is a proportional preview, not a cutting plan or price calculator; above 2.5 metres the workshop adds pattern repeats and confirms the final setout.

Need help matching your fretwork?

You do not need a catalogue code to ask for a quote. Send a photo, drawing or sample details with your measurements. The Bayswater workshop can review what you need and provide a written quotation.

Send a photo or drawing for a quote Choose standard sizes and prices

What measurements should I send?

Clear width of each opening and required overall drop.
Design code or a straight-on photograph of the existing panel.
Panel quantity and motif choice where applicable. Confirm curved or arched dimensions separately.
Your delivery postcode and any access restrictions. If you do not have every measurement yet, tell us what you know.

Quote request only — nothing is ordered or charged when you enquire.

Victorian timber fretwork for a restoration

For a Victorian timber fretwork repair, match the surviving design before choosing a replacement. A verandah panel, an internal hallway arch and an assembled frieze use different components and materials. Compare the original pattern, opening width and available drop with the drawings on this page.

Send square-on photographs beside a tape measure, or a surviving sample, if the design is outside the catalogue. Heritage makes and matches decorative timber in Bayswater, Melbourne, and supplies customers across Australia. Use the fretwork matching enquiry for a repair, or preview the 19 internal HFR/DFR patterns at your opening size. For a verandah, compare the adjoining posts and corner brackets as well as the fretwork.

For external LOSP H3 treated pine, follow the priming and care instructions before fitting. Internal fretwork is a separate interior product; the workshop confirms the material, finished size and setout for your quote.

From original to reproduction

Fretwork reproduced from existing patterns

Original samples and new workshop pieces show how curved, geometric and turned fretwork details can be reproduced.

Curved fretwork and motifs

Compare the original painted sample with the new timber reproduction, including the curved openings and decorative motifs.

Fretwork and corner brackets

The painted pieces are shown above the new timber versions, making the repeated pattern and bracket profiles easy to compare.

Geometric arched fretwork

Workshop pieces and building details show the geometric pattern, curved lower edge and small decorative blocks.

Turned fretwork matching

An original painted section is shown alongside a new timber panel, with matching turned details and circular openings.

Send a clear photograph and your approximate measurements. Include a close-up of the profile and a wider view of the whole piece.

Send a fretwork photo for a matching quote

From the existing photo gallery

Fretwork examples from our gallery

See pierced panels in the workshop and arched fretwork in place. Use these photographs to explain the pattern and proportions you want, then compare the designs or send us your existing timber to match.

Workshop: pierced fretwork panels
Pierced fretwork panels laid out in a matching run. Send the clear opening width, required panel height and a photograph of the pattern you need.
Ask about matching fretwork
Design reference: arched verandah fretwork
Arched fretwork follows the verandah openings on this weatherboard cottage. Use it as a proportion reference; the exact design code and project supply are not identified.
See more arched fretwork examples

Compare fretwork designs and prices · Documented Oslo Hotel fretwork supply

Documented interior fretwork: HFR5 on House Rules, 2018

Prices in the shop

See the prices and add to a quote.

Choose external fretwork, internal fretwork or frieze panels in the shop. Check the selected product’s dimensions and price unit; custom requirements are confirmed in your written quote. Nothing is charged online — add what you need and send it to us as one quote request.

What you get

Australian made — every product, made in our Bayswater workshop since 1984
25 year guarantee — on external LOSP H3 treated pine, above ground
An answer within one business day — we reply to enquiries and quote requests
In stock, or made in 1 to 4 weeks — some of the range is in stock; the rest is made to order
Timber-profile matching — from a photograph, drawing or sample

What external fretwork designs are available?

Our external fretwork runs FR1, FR2, FR3, FR4, FR5, FR8, FR9 and FR10. FR2, FR3, FR4, FR5 and FR8 are assembled at 300mm overall depth. FR4 is made with or without a decorative motif, and the motifs run A to G at 90 x 19 x 235mm each. FR4, FR5 and FR8 come assembled or as a kit for your builder; FR1, FR2, FR3, FR9 and FR10 come assembled. FR1 and FR4 are also made as arched panels — see timber arches.

Can I buy the fretwork components separately?

Yes, which suits a repair to an otherwise sound run. The bottom rail, code FRRA, is 42 x 42mm treated pine machined with a 19 x 12mm trench that the fretwork seats into, and the matching fillet is 19 x 12 x 1000mm. FR4 slats are 42 x 19 x 235mm. The FR8 squiggle motif is 128 x 19 x 235mm and its slat 53 x 19 x 235mm.

FR2 complete timber fretwork panel with circular motifs between top and bottom rails — FR2 complete fretwork panel

What sizes do the frieze panels come in?

Frieze panels are sold in four ranges, and the range letter is the height. Range A is SA1FW to SA27FW at 270mm — twenty-seven patterns, the widest choice on the page. Range B is SB1FW to SB6FW at 400mm. Range C is SC1FW to SC8FW, also at 270mm — SC8FW is included in the profile drawings below. Range G is SG1FW to SG12FW at 440mm, the deepest band. Fifty-three frieze patterns are priced and pictured in total (A 27, B 6, C 8, G 12). The shop’s 54-product frieze collection also includes the separate FRI5 Grapevine design. Width in every range is made to your opening, and both fretwork and frieze panels show the unit for each code: per lineal metre or each. Check the selected product’s unit before adding it to your quote.

What is external fretwork made from?

Our external fretwork and frieze panels are made from LOSP H3 treated pine, Australian made. The H3 rating covers outdoor use above ground, which is exactly what a frieze does: sits in the weather holding a fine cut pattern for decades. As external LOSP H3 treated pine used above ground, they carry our 25 year guarantee. Prime all six faces with two thin coats of oil-based primer before fixing, then topcoat.

FR3 complete timber fretwork panel with repeated arched openings — FR3 complete fretwork panel

Is internal fretwork made the same way?

No, and this is the difference that catches people out. Internal fretwork is built as a clear pine frame with an MDF insert, because it never sees weather. Clear pine is untreated and MDF is not treated pine, so internal fretwork is not covered by the 25 year guarantee — on either count. It is made to be painted or finished to match your existing joinery, and the different construction is also why it prices differently from the external range.

The internal patterns shown on this site are HFR1 to HFR5 and HFR8, DFR10, and the assembled FRI1 Nouveau and FRI3 Sunburst — nine designs. The workshop makes more than that: nineteen internal patterns are drawn in our CAD file — HFR1 to HFR5, HFR8 to HFR19, plus DFR10 and DFR11 — and FRI5 Grapevine is made as a third assembled pattern. HFR6 and HFR7 are not listed; choose from the named patterns or send a photo for a matching quote. The fretwork size visualiser draws all nineteen at your own opening size. Enter the clear opening width and height in millimetres in the visualiser. Shop lengths are entered in metres where the selected product is priced per lineal metre; the workshop confirms manufacture in your written quote.

Open the internal fretwork visualiser, choose a pattern, and enter the clear width and height of the opening. It redraws the panel at those proportions so you can compare designs before requesting a quote.

How do I measure for a replacement panel?

Three numbers order a panel. Take the post-to-post width from the inside face of one post to the inside face of the next, at more than one height if the posts are old, because timber bows. For an arched panel, add the side drop — how far the timber comes down beside each post — and the centre drop at the middle of the opening. For a straight panel, width and overall height are enough. Photograph the run square-on with a tape measure in shot, and if you can safely get the original down, send it: a sample beats every measurement. Ask about our timber-profile matching service. Call 03 9720 1996.

FR4 motif range, pierced slats between rails, shown as a render

Choosing fretwork for a repair or a complete verandah

Start with the location: an internal hallway arch and an exposed verandah panel need different materials. Then choose between a component repair, an assembled fretwork section and a frieze panel. Keep the design code with your measurements so a quote for a replacement slat is not confused with a quote for the whole panel. Our internal versus external fretwork guide explains the material distinction.

Record each clear opening separately rather than assuming every bay is identical. Include the required depth and whether the panel is straight or arched; an arch also needs its side and centre drops. For a matching repair, photograph the complete pattern and a surviving component beside a tape measure. The fretwork preview guide helps compare a design before ordering. A visual preview helps with appearance; use your measured openings and the confirmed order specification for manufacture.

Request a fretwork or frieze quote with the design code, opening measurements, number of panels and delivery postcode. State whether you need an assembled panel, an available kit, or individual repair components. See fretwork prices for internal panels, external panels and components or frieze panel prices by range before sending your selection.

In place

Fretwork examples and installations.

FR8 complete fretwork panel
HFR19 decorative fretwork across an internal hallway opening
Examples of straight and arched fretwork panels, workshop pieces and verandah installations
Timber fretwork frieze panel, in the Heritage workshop, circular fretwork panels in the workshop
Timber fretwork frieze panel, on a period home
Timber fretwork panels with a pierced sunburst pattern, on the workshop bench

Talk to the workshop

Tell us the code and the size.

Workshop852 Mountain Highway, Bayswater VIC 3153
DeliveryAustralia wide

Call 03 9720 1996 Email us the full fretwork price list frieze panel prices per lineal metre

Product and ordering questions

How tall are the frieze panels?

Frieze panels in the A and C ranges are 270mm high, the B range is 400mm high and the G range is 440mm high. Width is made to what you require.

Do you make fretwork to a size that is not standard?

Yes. Internal fretwork is made to size, height and width as you require, and we can also supply custom made products based on your size and style requirements.
