What’s what · 29 parts · Heritage & Decorative Timber, Bayswater Victoria
Hardly anybody rings up asking for a corner bracket. They ring up asking for the curly bit under the verandah post, and that is a perfectly good way to order one.
But if you would rather work it out first, here are two photographs of real houses with every timber part marked. Pick a number and you get the trade name, what it does, the product code and the page to order it from.
The photographs · 14 of the 29 marked in place
Nine numbers are marked on the street front and nine under the verandah. Four parts appear on both photographs, so those eighteen numbers name fourteen different parts. The remaining fifteen of the twenty-nine are in the range below.
Everything a photograph of a front verandah cannot show you
Every part on the photograph carries a number. Click one, or tab to it, and this card tells you what it is called, what it does, the product code, the sizes we make it in and the page to order it from. It stays here while you look at the next one.
If you would rather not hunt, type what you call it in the box above. “Curly bit”, “lace”, “spindles” and “post cap” all land on the right thing.
Also called
gable spike · apex ornament · roof point · gable top · spire · the pointy thing on the gable · roof spike
The turning at the apex of a gable, where the two barge boards meet. It also finishes a lych gate, a porch gable or a cubby house.
Also called
gable insert · gable end · gable panel · sunburst · gable fretwork · the fan in the gable · gable triangle
Fills the triangle of the gable above the wall plate. Made to your pitch, so your roof does not have to be a standard one.
Also called
roof vent · air vent · gable louvre · loft vent · gable window · the round vent in the gable
Lets the roof space breathe through the gable end. Flywire is fitted to the back so nothing gets in.
Also called
rake board · verge board · gable trim · fascia moulding · the board down the side of the gable · bargeboard
The board running down the sloping edge of a gable, and the relief moulding used to trim and frame it.
Also called
soffit bracket · modillion · eave corbel · little brackets under the eaves · the small ones under the gutter
The small bracket repeated at intervals along the underside of the eaves or the frieze board. Bought by the run, not the pair.
Also called
bullnose · bull nose · roof curve · curved rafter · verandah bull · the curved bit of the verandah roof · bullnosed verandah
The shaped rafter that gives a verandah roof its profile, running from the wall out over the posts. Cut to any radius to suit the roll of roofing.
Also called
the curly bit under the post · curly bit · spandrel · angle bracket · verandah bracket · fretwork bracket · corner piece · the twiddly bit on the corner
Fills the angle where the post head meets the beam. The same bracket dresses a gazebo, a carport, a pergola or a lych gate, and doubles as a shelf bracket.
Also called
frieze · lace panel · valance · frieze board · verandah lace · the deep lace under the roof · friezework
The flat cut panel that runs the full span between the posts, set as a continuous band under the beam. Deeper than fretwork, and the piece most people mean when they say “lace”.
Also called
fretwork · lace · lacework · gingerbread · valance · verandah frill · the curly bit between the posts · arch · verandah arch · scroll
The cut panel hung under the beam between two post heads, often arched. Ours is cut timber, not cast iron, so it takes paint and does not rust.
Also called
turned post · porch post · veranda post · pillar · column · front post · the posts holding the roof up · verandah pole
The turned post carrying the verandah beam and roof. It stands on the deck or a stirrup, and takes the corner bracket and the frieze either side of its head. All eight designs are Federation.
Also called
post cap · ball top · fence post cap · post top · knob · capitol · acorn · windsor · pyramid top · the ball on top of the post
Caps the top of a post or a fence post. Flat bottomed, so it sits straight down on the post with no joint to cut.
Also called
dropper · pendant · drop · hanging post · half post · newel · end post · stair post · banister post · corner post · the short post
A dropper is the half-turning fixed to a wall or a post where a full post will not fit, finishing the end of a frieze or balustrade run. A newel is the full post that starts, turns or ends a run of balustrade or a stair flight.
Also called
railing · infill panel · spindles · pickets · balusters · banister · the bit between the posts · rail panel · balustrading
The panel filling the gap between posts along a verandah, a deck or a stair flight. It arrives fully assembled, as a panel, ready to fix — not as a box of sticks.
Also called
top rail · banister rail · hand rail · grab rail · the rail on top
The rail along the top of a balustrade, rebated on the underside so the assembled panel drops straight into it.
Also called
bottom rail · sill rail · lower rail · sole rail · the rail at the bottom · kick rail
The rail under the balusters, rebated to match the handrail above so the panel is captured top and bottom. The fillet fills the rebate where it would otherwise show.
Also called
flyscreen door · fly door · front screen · security screen door · wire door · the door with the wire in it
A decorative timber screen door made to fit your existing door frame. Measure the frame, not the door. Beading to hold the flywire is included.
Also called
window hood · awning · door canopy · window roof · bonnet · the little roof over the window · window awning
A small roof over a window or a door. Shade in summer, shelter from rain in winter, and it takes load off the heating and cooling. The shaped ends are sold singly, so a canopy takes two.
Also called
carport · gazebo · pergola · garage · portico · car port · the roof over the driveway
Not one product but the same parts assembled: posts, corner brackets, fretwork, gable infill and a finial, framed to cover a car, a path or a seat. Built to match the house it stands beside.
Also called
gate · garden gate · picket gate · front gate · driveway gate · heritage gate · side gate
A made-to-order period gate to match the fence, the verandah or the house. Twenty-one named patterns. Posts are not included.
Also called
lych gate · lynch gate · roofed gate · covered gate · entry arbour · gateway arch · the gate with a roof on it · arbour
A roofed entry gate over a front path — the gate, its posts and a small pitched roof, usually finished with a finial and corner brackets. Wrought iron gate tops, peep-hole inserts and rosettes are available with it.
Also called
privacy screen · decorative screen · lattice panel · screen panel · garden screen · feature screen · air con screen · the screen outside
A fixed decorative panel that screens a courtyard, a balcony, a deck or an air-conditioning unit while still letting light and air through. These are fixed panels, not doors.
Also called
stairs · steps · front steps · treads · stringers · staircase · step kit · back steps
Stringers and treads cut and ready to assemble, in LOSP pine, CCA pine, Merbau, or a premium kit in deeper material.
Also called
sawtooth · centre stringer · middle stringer · zigzag stringer · centre support · cut string · the bit under the middle of the stairs
The stepped centre spine that runs up the middle of a wide flight, under the treads and between the two outer stringers, so the treads do not flex underfoot. You cannot see it once the stair is built. Needed once a stair is over 1200mm wide, and already included in a complete kit at that width.
Also called
internal fretwork · hall arch · hallway arch · archway panel · room divider · fretwork arch · corridor arch · the arch in the hall · passage arch
The cut panel set across an internal opening — a hallway, a doorway between two rooms, an alcove. Scaled to your opening rather than cut down from a fixed panel.
Also called
architrave · door surround · window frame moulding · casing · skirting · skirting board · baseboard · moulding · curved skirting · arched architrave · the trim round the door
The moulding that frames a door or a window, and the board along the bottom of the wall. Curved and arched work is the awkward one, and it is the one the workshop is set up for — any internal or external radius, matched to a profile you already have.
Also called
rosette · corner block · plinth block · rose block · architrave block · roundel · boss · the square block in the corner of the door frame
The block that turns the corner of an architrave so the mitre does not have to. Period joinery used them everywhere, and they forgive an out-of-square opening. Round turned rosettes finish the cut end of a gable fascia outside.
Also called
corbel · console · shelf bracket · mantel bracket · scroll bracket · bracket block · the bracket under the mantelpiece
The shaped bracket that carries a shelf, a canopy, a mantelpiece or a bench return. Turned or carved.
Also called
pelmet · curtain pelmet · valance box · curtain box · cornice board · curtain top · the box over the curtains
The shaped board that hides a curtain track above a window, inside the house. The hanging space behind it swallows the track and the top of the curtain.
Also called
louvre · louver · shutter · slatted panel · vent panel · blind panel · the slatted door
Slatted panels for doors, windows, wardrobes and screening, made to the opening.
What it is made from
Everything is Australian made, in Bayswater. Four rules cover the whole range, and they are worth reading once because customers get the last one wrong more than any other.
Every product is LOSP H3 treated pine unless the page says hardwood, Merbau or MDF.
Clear pine is not treated pine. Corbels are clear pine, made for staining or painting.
25 year guarantee on all external LOSP H3 treated pine products used above ground. All three parts of that sentence matter: external, LOSP H3, above ground.
Internal fretwork is an 18mm MDF insert in a clear pine frame. It is for inside the house and it carries no guarantee. External fretwork is treated pine and does. They look alike in a photograph and they are not the same product.
